GX12-2-3-4-5-6-7 Pin Connector Snap On Threaded Locking Type GX12-6P
GX12‑6 is a 6‑pin circular aviation connector set including male plug and female socket, both equipped with rubber strain‑relief boot to protect cable root from bending and pulling damage. Constructed with nickel‑plated zinc‑alloy housing, silver‑plated copper contacts and bakelite insulator with solder‑cup welding process, it adopts screw‑locking anti‑vibration coupling. Rated 5A 250V AC with IP54‑IP55 dust‑splash protection, it realizes reliable cable‑to‑cable power connection, widely used for industrial instruments, monitoring device and lighting equipment interconnection.
Product display
Product Performance Details
| Product model |
GX12-6P |
Contact Piece |
Gold plating of copper |
| Shell Material |
Zinc alloy |
Insulation Resistance |
≥500MΩ |
| Locking Method |
M12*1.0 Thread |
Working Voltage |
125V |
| Temperature Rise |
≤ 50℃ |
Working Temperature |
-20℃ ~ +85℃ |
| Contact Resistance |
≤5MΩ |
Working Current |
5A |
| Withstand voltage |
1500 V |
Mechanical life |
500 times |
Physical product display
External dimensions of the product
Related product recommendations
Display of Strength
Production Plant Area
Machining production workshop
Precision Assembly Production Workshop
Glass-to-metal sealed production workshop
Obtained Certification Certificate
Customer visit
Product packaging
Packaging and Shipping
- Standard export carton
- As per customized specifications such as logo or others According to customers' requirements
- Delivery time:Within 24 hours for stocks, 3-4 weeks for mass production orders. (based on different quantities,ODM, etc.)
